I am now organised again in support of with Tony Jeffree's DivisionMaster digital indexer. As of today I have 12 boxes left for the original Divisionmaster which I can supply as finished units or a kits. There is one finished unit and one kit now on the shelf and I've restored the buying link here. I have another two units being assembled and parts for a couple more kits which will be sorted soon. The DMSuper is a little more difficult as I don't have the Micromill operational at the moment so will have to hand craft a case for that unit having just sold the last of the machined cases. Getting the mill operational again is something I hope to achieve over this summer and income from these parts will help achieve that!

Tony's original site is still accessible and has some useful examples of using the divisionmaster.

Top View Angled
DMComplete

The Construction Guide DivisionmasterConstructionGuide is available to download so you can see what is involved in building one. This has been updated with some additional information suggested by the early builders of the kit..
Finally developed a fuller Rotary Table CNC Options document, and you can review the 6inch Rotary Table Conversion Guide for more details on converting as well as the 8inch Rotary Table Conversion Guide but both of these do need bringing up to date.

Please check the bottom of the list for the extra shipping costs outside the United Kingdom

DMPCBs DivisionMaster PCB Kit
Kit consists of a pair of printed circuit boards and a programmed PIC
Documentation for building can be found here
£60.00

DMFullKit DivisionMaster Full Kit
Everything you need to build the controller box.
£220.00

DMComplete DivisionMaster Assembled Unit
Built to order - please allow a few days before shipment
This unit is DC powered and needs an external 24V supply such as the power pack below.
£250.00

PSU-24V2A5 24V 2.5A Switchmode Powerpack
PSC-Fig8-UK PSC-Fig8-Euro  PSC-Fig8-USA
£40.00
Mains Lead
DMS7 DivisionMaster Super Unit
DivisionMaster Super unit with larger backlit display and an integral 4.2Amp driver with 45V 160W Power Supply all built into a 22cm by 14.6cm by 10cm diecast box
Built to order - please allow a few days before shipment
£380.00 No way to machine case currently but contact me if you are interested. Rest of kit available.
DivisionmasterConstructionGuideMk2 Bound Hard Copy of the construction guide including a set of schematics
and a copy of the user manual DivisionmasterManual-LSCES
£10.00

I do at least have a good printer, the laminater and binder.
Guide to choosing a stepper motor Guides - 6inch Rotary Table Conversion Guide, 8inch Rotary Table Conversion Guide
Myford Lathe Attachment

Hemingway Kits provide a suitable conversion for the Super 7 and ML7 to directly drive the bull wheel. Their VHD Upgrade Kit which can be adapted to take a NEMA23 stepper motor.


4-6MotorMount 4" to 6" Tables - Vertex HV4 (4"), Homge HHV150, Myford and Vertex HV6 (6" ) - For NEMA23 Motor
Select the shaft sizes for your motor and table before ordering.

The kit is supplied with a torque plate and two shaft plates of the correct size for the coupling.
£75.00 Currently unable to supply, in addition the coupling price is a lot higher these days!
180NcmMotor Assembly NEMA23 190Ncm Stepper Motor ready configured for use with the DivisionMaster with 2mt Lead.
Wired series mode for 2.1Amp rating to match the Standard DivisionMaster
Only one left.
Motor Assembly Details
£60.00

180NcmMotor Assembly NEMA23 220Ncm Stepper Motor ready configured for use with the DivisionMaster with 2mt Lead.
Wired series mode for 2.1Amp rating to match the Standard DivisionMaster
One in stock and able to build more.
Motor Assembly Details
£65.00

3NmStepperMotorAssembly NEMA23 310Ncm Stepper Motor ready configured for use with the DivisionMaster with 2mt Lead.
Wired for 4.2Amp working with DMSuper
See 180Ncm Motor Assembly Details for example ... updated crib sheet to follow.
£75.00 Some stock of parts, needs sorting



European Insured Delivery ( International Signed For )
For DivisionMaster or Kit ... Additional parts shipping will be quoted - please email

£15.00 UK sales only short term
  Overseas Insured Delivery
Rest of world outside Europe ( International Signed For )
For DivisionMaster or Kit ... Additional parts shipping will be quoted - please email
£30.00 UK sales only short term


Shipping will be added to the order up to £10.00 - please add the additional shipping for Europe (outside the UK) or the Rest of the World.
Paypal will produce a total in your preferred currency at the current conversion rate.

Contact me direct for alternative prices, packages, or the additional parts listed in the complete parts list Lester Caine
